The following are representative size combinations for product selection, not a confirmed stock list. Final sizes should be checked against the actual MALAXY product drawings and available specifications.
Model / Size (mm) | Typical Application |
|---|
3.0 × 20 | Small wood components |
3.5 × 25 | Furniture and woodworking |
4.0 × 30 | General wood fastening |
4.0 × 40 | Furniture and panel assembly |
4.5 × 50 | Wood fixtures and fittings |
5.0 × 50 | Timber and wood-based panels |
5.0 × 60 | General construction woodworking |
6.0 × 80 | Longer wood fastening applications |
6.0 × 100 | Timber assembly, subject to design requirements |
Core Parameters
Parameter | Specifications |
|---|
Product Name | Torx Wood Screw |
Drive Type | Torx / Star Drive |
Material | Carbon Steel / Stainless Steel 304 / Stainless Steel 316, subject to availability |
Diameter | Multiple metric and imperial sizes |
Length | Multiple lengths according to specifications |
Head Style | Countersunk / Double Countersunk / Wafer Head, depending on design |
Thread Type | Wood Screw Thread |
Drive Size | T10 / T15 / T20 / T25 / T30 / Other sizes, depending on screw dimensions |
Surface Finish | Zinc Plated / Yellow Zinc / Other specified finishes, subject to availability |
Application | Timber / Chipboard / MDF / Furniture / Wood Assembly |
Packaging | Bulk / Carton / Small Box / Customized Packaging |
Customization | Size / Material / Head Style / Finish / Packaging |
Specification note: Torx wood screws are generally identified by diameter, length, head style and drive size rather than by a single universal model number. Do not assign a DIN or ISO standard unless the actual product conforms to that standard.
Torx Wood Screws for Timber, Chipboard and Construction Applications
MALAXY Torx Wood Screws are designed for reliable fastening in woodworking, furniture manufacturing, cabinetry and general construction applications involving wood and suitable wood-based materials. Featuring a six-lobe star drive, these screws provide effective driver-bit engagement and help reduce driver slippage during installation when used with the correct Torx bit.
Available in different diameters, lengths, head styles and material options, Torx drive wood screws can be selected for various assembly requirements. Carbon steel versions can be supplied with specified protective finishes, while selected stainless steel options are available for applications requiring different corrosion-resistance properties.
MALAXY supports B2B buyers with bulk supply, specification options and customized packaging according to project and purchasing requirements.
Key Features
Torx Star Drive: Six-lobe drive design for effective bit engagement and controlled installation.
Wood Fastening: Suitable for timber, chipboard, MDF and other compatible wood-based materials.
Multiple Sizes: Various diameters and lengths available according to product specifications.
Material Options: Carbon steel and selected stainless steel grades.
Surface Finish Options: Zinc plating and other specified finishes, subject to availability.
Flexible Head Styles: Countersunk, double countersunk and other configurations according to design.
OEM Customization: Custom specifications available according to drawings or samples.
Bulk Packaging: Cartons, small boxes and customized packaging for wholesale orders.
Typical Applications
Furniture Assembly · Cabinet Manufacturing · Timber Construction · Chipboard Fastening · MDF Assembly · Woodworking · Suitable Decking Applications
For exterior decking or structural timber projects, select a screw specifically designed and tested for the intended environment and loading conditions.
Why Choose MALAXY?
MALAXY is a fastener manufacturer and exporter based in Zhejiang, China, with manufacturing experience dating back to 2001. We supply a range of screws, bolts, nuts, anchors and other fastening products for international B2B markets.
With multiple product specifications and customized packaging options, MALAXY supports importers, wholesalers, distributors and manufacturers seeking dependable fastening supply.
Contact MALAXY for product specifications, drawings, samples and bulk quotations.
