Malaxy Bow Nuts, also known as lifting bow nuts or bow-shaped nuts, are specialized internally threaded fasteners designed for straight lifting, restraint, and hinge-type fastening applications. Functionally similar to eye nuts, bow nuts are suitable for vertical lifting and load handling, making them an essential component in marine, shipbuilding, construction, industrial rigging, and heavy machinery assembly.
Our bow nuts are manufactured to international standards including DIN 80704 and BS 3974 Part 1 (1974) , ensuring dimensional accuracy, consistent quality, and full compliance with global engineering requirements.
Key Features & Technical Specifications
Drop Forged Construction: Produced via precision drop forging process for superior strength, structural integrity, and uniform grain flow. Hot-working hardness can reach property classes up to 6.8, 8.8, 9.8, 10.9, and 12.9.
SWL Markings: Safe Working Load is forged on the side of each unit for clear guidance and safety compliance. Warning: Never exceed the rated SWL—ensure eyebolt and thread compatibility before use.
Wide Size Range: Available in metric sizes from M6 to M42, covering M6, M8, M10, M12, M14, M16, M18, M20, M22, M24, M30, M36, and M42.
High-Strength Materials:
Carbon Steel (high tensile, rust-resistant)
Stainless Steel A2 (304) / A4 (316) – marine grade, excellent corrosion resistance
Brass – machinable, ductile, corrosion resistant
Surface Finishes Available: Self colour (plain), electro-galvanized, zinc plated (white/blue/yellow passivation), hot-dip galvanized, blackened
Load Capacity Range: Working load limits from 230 kg (M8) up to 7,400 kg (M42)
Applications
Marine & Shipbuilding: Hinge-type fastenings for ship windows, hatches, deck hardware, and marine rigging systems
Lifting & Rigging: Straight lifting operations in industrial and construction environments, used with shackles, eye plates, turnbuckles, and wire rope fittings
Construction & Infrastructure: Building frameworks, railing systems, shade structures, and waterfront projects
Industrial Machinery: Loading and restraint applications in heavy machinery and equipment assembly
Quality Assurance & Compliance
Manufactured in accordance with DIN 80704 and BS 3974 standards
Property classes meet ISO 898-2 and ISO 3506-2 requirements
CE marking available upon request for certified lifting applications
Rigorous in-process and final quality inspections
Customization Services
Malaxy offers OEM/ODM services for non-standard sizes, special materials, custom finishes, and parts made to customer drawings.
Why Choose Malaxy?
As a leading fastener manufacturer in China, Malaxy combines decades of industry expertise with advanced production capabilities, rigorous quality control, and competitive pricing. We are your trusted partner for industrial fastening solutions.
For inquiries, quotations, or technical support, please contact our sales team. We look forward to supporting your projects with reliable, high-quality bow nuts and professional service.
