Self-Tapping Screws – Cut or Form Threads in Metal, Plastic & Wood Without Pre-Tapped Holes

MALAXY offers self-tapping screws in carbon steel (grade 1022, classes 4.8–10.9) and stainless steel (304, 316, 410). Thread-forming and thread-cutting types available. Pan head, flat countersunk, hex washer head styles with Phillips, Pozidriv, or Torx drive. Ideal for automotive, electronics, sheet metal, HVAC, and plastic assemblies. Custom finishes and OEM supported.

Product Description

Self-Tapping Screws | DIN 7981 | ISO 7049 | ANSI B18.6.4

Overview

Self-tapping screws create their own mating threads when driven into a pre-drilled or pre-punched hole. They eliminate the need for pre-tapped holes or nuts, reducing assembly time and cost.

MALAXY manufactures two main types:

Thread-forming screws – displace material, no chips, ideal for plastics and soft metals.
Thread-cutting screws – remove material, precise threads, ideal for hard metals and castings.

Material & Grades

Material	Grade	Tensile Strength	Corrosion Resistance
Carbon steel	1022 (case-hardened)	800–1000 MPa	Low (needs coating)
Carbon steel	10B21 / 10B22	1000–1200 MPa	Low (needs coating)
Carbon steel	Class 8.8 / 10.9	800–1040 MPa	Low (needs coating)
Stainless steel	304 (A2 / 18-8)	500–700 MPa	High
Stainless steel	316 (A4)	500–700 MPa	Superior (marine grade)
Stainless steel	410 (martensitic)	500–700 MPa	Moderate

Head Styles & Drives

Head styles: Pan head, flat countersunk, raised countersunk (oval), hex head, hex washer head, truss head, cheese head.
Drive types: Phillips (H), Pozidriv (Z), Slotted, Torx, Hex socket, Square.
